Automotive training stand for car electronics MSAE01

Automotive Electrical System and EV Training Equipment

AutoEDU

Product number: MSAE01

ASE category: A6

Training stand designed for hands-on education in automotive electronic systems. It includes multiple removable modules, allowing students to individually test, measure, and analyze a wide range of automotive sensors and actuators. The stand provides a controlled environment for learning signal processing, sensor calibration, and troubleshooting electrical faults.

Request a quote

Check our catalog and product data sheet

Features

Includes 16 different sensor and actuator modules, such as Hall sensor, knock sensor, mass airflow meter, and fuel level sensor.
Modules can be detached for independent analysis and measurement.
Allows real-time signal monitoring using diagnostic tools such as oscilloscopes and multimeters.
Enables simulation of faulty conditions for troubleshooting exercises.
Supports both analog and digital signal analysis, teaching fundamental and advanced electronic control principles.
Built on a sturdy and mobile stand for easy classroom integration.
Sensor types:
- Hall sensor
- Accelerator pedal position sensor
- Absolute pressure sensor
- Knock sensor
- Oxygen sensor
- Oil pressure switch
- Liquid level sensor
- Differential pressure sensor
- Air flow meter
- EGR actuator
- Limit pressure increase solenoid valve
- Oil level and temperature sensor
- Air mass meter
- Engine temperature sensor / Air temperature sensor
- Direction of rotation sensor
- Fuel level sensor

Value for Students

Enables direct measurement and analysis of real automotive sensors, including Hall sensors, pressure sensors, temperature sensors, oxygen sensors, and more.
Develops skills in interpreting sensor data, understanding signal variations, and troubleshooting faults in electronic control systems.
Provides hands-on experience with actuators such as EGR valves and solenoid control, reinforcing knowledge of engine and emissions management.
Teaches voltage, resistance, and frequency signal testing, preparing students for real-world automotive diagnostics.
Supports learning about electronic fuel injection, ignition timing adjustments, and engine control unit (ECU) interactions.

Value for Instructors

Offers a structured platform for teaching automotive electronic components and their applications.
Provides a modular approach to training, allowing instructors to focus on individual sensors and actuators.
Enables easy demonstration of working principles through direct measurements and controlled fault simulations.
Designed for step-by-step instruction, suitable for beginners and advanced students.
Supports group training with multiple removable modules, ensuring all students get hands-on experience.

Specifications

Dimensions: Length 1360 mm (53.54 in); Width 500 mm (19.69 in); Height 1820 mm (71.65 in)
Weight: Approx. ~ 60 kg (~132 lbs)
Power supply: 12V power supply from 220V (110V) household electricity network
Compatibility: Works with standard automotive diagnostic tools
Product number: MSAE01
