Differential With Electronic Control With Electro-Hydraulic Joints (Haldex Type) AE411291M

Compact training system featuring an electronically controlled differential with electro-hydraulic joint, Haldex-type configuration. The unit includes a pinion-crown gear group, differential mechanism, multi-disk clutch pack, control valve, hydraulic piston, and output shafts. Mounted on a stable tabletop frame, the system is designed to clearly demonstrate the principles of torque distribution, electronic actuation, and electro-hydraulic clutch control in modern all-wheel-drive systems.

• Components included: pinion-crown gear set, differential, multi-disk clutch, control valve, hydraulic piston, output shafts.
• Control: electronic and hydraulic.
• Type: Haldex-style electro-hydraulic differential.
• Mounting: table stand.
• Weight: 20 kg (44.1 lbs).
• Dimensions: 400 x 600 x 400 mm (15.75 x 23.62 x 15.75 in).
• Product number: AE411291M

• Learn torque transfer principles in electronically controlled all-wheel-drive systems.
• Study the function of pinion-crown gear interaction and mechanical power distribution.
• Understand how the multi-disk clutch modulates torque using hydraulic pressure.
• Analyze the role of the control valve and hydraulic piston in real-time torque engagement.
• Observe mechanical motion from input through differential to output shafts.
• Identify functional components used in modern AWD vehicles.
• Gain foundational knowledge for diagnosing differential and hydraulic actuator systems.
• Explore applications in automotive learning using a real-world drivetrain configuration.

• Demonstrates active torque control using real components.
• Simplifies complex drivetrain concepts in AWD systems.
• Provides safe, hands-on operation without live vehicle systems.
• Enhances classroom explanation of Haldex-type differential operation.
• Useful for vocational training and professional automotive education.
• Allows repeated setup demonstrations with no need for running engine.
• Compact tabletop size ideal for limited classroom spaces.
