Fuller 13 Speed Gearbox Cutaway Educational Trainer AE411070M

AutoEDU

Product number: AE411070M

ASE category: A2

Specialized training tool designed for hands-on learning in heavy vehicle transmission systems. This non-synchronized gearbox, commonly used in 300/400HP commercial vehicles, features a dual-section design with mechanical control for lower gears and pneumatic control for speed-select gears. The model includes chromed and galvanized components for durability and is mounted on a mobile stand for easy classroom use. Manual operation through a handwheel allows students to explore both mechanical and pneumatic control principles, while auxiliary shafts ensure equal stress distribution for enhanced understanding of gearbox durability.

Request a quote

Check our catalog and product data sheet

Download the Full AutoEDU Product Catalogue

Enter your details to receive the AutoEDU catalogue with automotive training systems, laboratory equipment, technical specifications, and solutions for universities, technical colleges, and training centers.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Features

Based on a Fuller 13-speed gearbox used in 300/400HP commercial vehicles.
Manual and pneumatic gear control systems for comprehensive study of both mechanical and pneumatic gear shifts.
Divided into two operational parts: the engine side with lower gears and the output shaft side with speed-select gears.
Color-coded and chromed parts to visually distinguish various gears, shafts, and selectors, aiding in component identification.
Manually operated through a handwheel to replicate real-world gear shifts.
Mounted on a robust stand with wheels, providing ease of mobility within the classroom.

Value for Students

Heavy-duty, non-synchronized gearbox system found in commercial vehicles, focusing on mechanical and pneumatic control mechanisms.
Operation of 13-speed gearboxes by studying the separation of gear functions between engine and output shaft sides.
Learn to identify and differentiate gear systems, including the standard, low, and semi-low ratio gears, controlled manually and pneumatically.
Explore auxiliary shafts, designed to equally share shearing stress, promoting a deeper understanding of gearbox durability and load distribution.
Work directly with exposed, color-coded parts, including gears, shafts, and selectors, to visually identify functional elements and component interactions.
Examine gearbox cutaway sections that have been professionally painted and chromed to enhance clarity and durability, ensuring a longer lifespan for repeated educational use.

Value for Instructors

Fully functional cutaway model for detailed demonstration of heavy-duty gearbox mechanisms, aiding in the instruction of commercial vehicle transmission systems.
Enhances the learning process by offering students real-time visual access to mechanically and pneumatically controlled gears.
Ensures easy-to-use manual operation through a handwheel, allowing students to engage directly with the gearbox’s working principles.
The gearbox is mounted on a stand with wheels, ensuring easy movement within the classroom, maximizing space efficiency and student engagement.
Durable construction with chromed and galvanized components ensures the model withstands continuous use and offers a long-term educational resource.
Simplifies lesson preparation as the model clearly displays internal components, enabling instructors to focus on key concepts without additional setup.

Specifications

Dimensions: 1100 x 1000 x 1300 mm (43.31 in×39.37 in×51.18 in)
Weight: approx. 300 kg (660 lb)
Product number: AE411070M
