Gate Valve Cutaway AE513134S

Home

Cutaway Models - Engines, Gearboxes & Drivetrain

AutoEDU

Product number: AE513134S

Cross-sectioned industrial gate valve.
Manually operated handwheel with visible spindle and gate.
Display of flow passage and valve seat.
Rigid, stable base with mounting feet.

Request a quote

Check our catalog and product data sheet

Download the Full AutoEDU Product Catalogue

Enter your details to receive the AutoEDU catalogue with automotive training systems, laboratory equipment, technical specifications, and solutions for universities, technical colleges, and training centers.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Description

Educational model featuring a sectioned metallic gate valve mounted on a square base. Designed for training applications in fluid mechanics, hydraulic systems, and pipeline control. Used for technical demonstration of valve components, mechanical structure, and flow regulation mechanism in various systems including automotive, HVAC, and industrial piping.

Specifications

Valve type: Gate valve (manual operation).
Material: Metallic body with visible internal structure.
Weight: 1 kg (2.2 lbs).
Dimensions: 150 x 150 x 150 mm (5.91 x 5.91 x 5.91 in).
Product number: AE513134S.
