In-line Piston Pump Cutaway Educational Trainer AE412999M

This automotive training equipment features a precision-cut section of an in-line piston pump. The model exposes critical internal components including the pump head, suction and discharge valves, pistons, piston rods, and bearings. Designed for mechanical and fluid systems education, this training aid is ideal for hands-on demonstrations and component identification.

• Type: In-line piston pump cutaway.
• Components: Pump head, pistons, piston rods, bearings, suction/discharge valves.
• Dimensions: 250 × 250 × 400 mm (9.84 × 9.84 × 15.75 in).
• Weight: 11 kg (24.25 lbs).
• Product number: AE412999M

• Learn how in-line piston pumps operate in real mechanical and hydraulic systems.
• Identify and understand each key component: piston, piston rod, pump head, suction valve, and discharge valve.
• Observe fluid flow direction through suction and discharge chambers.
• Understand reciprocating motion principles in piston-driven systems.
• Inspect bearing arrangement and their role in supporting moving parts.
• Gain practical knowledge of pump construction used in automotive and industrial systems.

• Easy-to-use tool for demonstration of pump operation principles.
• Clear visibility of all internal moving parts for educational explanation.
• Supports teaching of fluid transfer concepts in automotive and mechanical engineering.
• Suitable for both beginner and advanced technical training sessions.
