Cutaway Models - Engines, Gearboxes & Drivetrain

/

Marine Inboard Diesel Engine Trainer 6/8 V-Cylinders cutaway AE47950E

Marine Inboard Diesel Engine Trainer 6/8 V-Cylinders cutaway AE47950E

AutoEDU

Product number: AE47950E

ASE category: A1

Marine diesel engine training unit for automotive education. Based on 6 or 8 V-cylinder engine (depending on availability). Electrically powered at 220 V with reduced-speed operation for mechanical observation. Fully sectioned with visible lubrication, fuel, and cooling systems. Color-coded and partially galvanized or chrome-plated components for clear identification and durability. Mounted on mobile stand. Designed as an automotive training aid for engine diagnostics, structure, and system layout.

Request a quote

Check our catalog and product data sheet

Features

Real marine diesel engine, 6 or 8 V-cylinders.
Full sectioning with visible internal systems.
Closed-circuit cooling.
Diesel fuel system with injection layout.
Lubrication system fully exposed.
220 V electric motor drive, low-speed rotation.
Mounted on wheeled steel stand.

Specifications

Engine type: 4-stroke marine diesel.
Configuration: V6 or V8.
Operation: Electric, 220 V, low-speed.
Cooling: Closed circuit.
Fuel system: Diesel injection.
Lubrication: Integrated, exposed.
Mounting: Mobile metal frame with wheels.

Value for Students

Understand marine diesel engine structure: V6 or V8 configuration.
Learn 4-stroke diesel operation: intake, compression, combustion, exhaust.
Identify internal parts: pistons, crankshaft, camshaft, cylinder heads.
Observe fuel injection paths and closed-loop cooling circuits.
Trace lubrication system: oil pump, galleries, channels.
Practice visual diagnostics and system recognition in real components.

Value for Instructors

Safe electric operation for controlled classroom use.
Visual learning via static and moving cutaway components.
Clear demonstration of engine systems with color separation.
No fuel or exhaust handling required.
Suitable for basic and advanced mechanical training courses.
