Petrol engine 16 valves GDI injection cutaway AE44600M/G

AutoEDU

Product number: AE44600M/G

ASE category: A1

The petrol (gasoline) engine with direct injection features a 4-cylinder, 16-valve configuration, incorporating a GDI injection system. This model is made from Mitsubishi GDI engine systems. Designed for high performance and compliance with strict emission standards, it includes a DOHC twin overhead camshaft and water cooling system. This cutaway model is carefully sectioned and mounted on a mobile stand, enabling detailed examination of internal systems.

Request a quote

Check our catalog and product data sheet

Download Catalogue

Features

4-cylinder petrol (gasoline) engine with direct injection and GDI injection.
DOHC twin overhead camshaft system for improved engine efficiency.
16 valves (4 per cylinder) with water cooling system.
Fully operational model allowing observation at reduced speed.
Mounted on a stand with wheels for enhanced mobility and classroom integration.
Professionally painted cutaway model, highlighting different circuits such as lubrication, fuel, and cooling systems.

Value for Students

Study GDI injection system with detailed insights into how fuel is delivered directly into the combustion chamber, enhancing understanding of atomization and fuel efficiency.
Analyze the GDI injection system to understand injection timing, sensor control, and electronic fuel management.
Observe the working of a twin overhead camshaft (DOHC) with water cooling, gaining insights into efficient thermal management in combustion engines.
Learn about lubricating and cooling systems through differentiated color-coded components, simplifying the identification of each system’s role in engine functionality.
Examine the dynamics of reduced-speed operation, providing a safe, controlled environment to view component movement in real-time.

Value for Instructors

Demonstrate OEM based technology and teach the working principles of a modern petrol (gasoline) engine, including direct injection, electronic injection, and twin overhead camshaft design.
Use color-coded cross-sections to easily guide students through different systems such as fuel, lubrication, and cooling circuits, making lessons more interactive and engaging.
Mobile stand design ensures that the engine model can be easily transported and integrated into different learning environments.
Electrical operation with reduced speed provides a safe and practical method to observe engine operations, eliminating risks associated with live engine demonstrations.

Specifications

Engine type: Mitsubishi GDI
Displacement: 1400-2000 cc
Dimensions: 900 x 1100 x 1250 mm (35.43 x 43.31 x 49.21 in)
Weight: 150 kg (330.69 lbs)
Product number: AE44600M/G
