Self-Priming Centrifugal Electric Pump Cutaway AE413030M

Self-priming centrifugal electric pump trainer equipped with an open impeller, integrated suction valve, and configured for handling liquids with suspended solids. Cutaway model design exposes internal components and flow pathways for visual learning.

• Pump type: Self-priming centrifugal electric.
• Impeller: Open type.
• Valve: Integrated suction valve.
• Product dimensions: 3500 x 3000 x 2500 mm (137.8 x 118.1 x 98.4 in).
• Weight: 6 kg (13.2 lbs).
• Product number: AE413030M

• Learn centrifugal pump working principle, including fluid acceleration through the impeller and conversion of velocity into pressure.
• Understand self-priming operation and the internal recirculation needed to evacuate air and lift fluids.
• Identify and study critical pump components such as open-type impeller, volute casing, suction valve, mechanical seal, and motor shaft.
• Observe how impeller shape and rotational speed influence flow and pressure characteristics.
• Visualize flow behavior in pumps handling solid-laden liquids.
• Analyze basic pump troubleshooting and failure modes such as cavitation, clogging, or seal wear.

• Effective visual demonstration tool for explaining pump hydraulics and self-priming action.
• Supports structured lessons on centrifugal pump types, component function, and fluid mechanics.
• Enables easy reference and pointing during lectures or exams.
• Reduces need for disassembly by offering permanent internal visibility.
