Truck diesel engine with Common Rail system (CR) cutaway Educational Trainer AE36082

AutoEDU

Product number: AE36082

ASE category: A1

Educational Trainer features sectioned Iveco engine equipped with a Common Rail (CR) fuel system. This model showcases 4-6 in-line cylinders, a camshaft, and detailed mechanical components including lubricating, fuel, and cooling systems. It operates electrically at 220 volts (110V US) with reduced speed for simulation of internal mechanics.

Request a quote

Check our catalog and product data sheet

Features

Sectioned Iveco engine with a Common Rail (CR) fuel system.
Includes 4-6 in-line cylinders, camshaft, and various mechanical parts.
Visible lubricating circuits, fuel system, and cooling system.
Operates at 220 volts (110V US), running at reduced speed for detailed observation.
Engine parts and systems are professionally painted in distinct colors for enhanced differentiation and learning.

Value for Students

Fully sectioned engine showcasing key components such as in-line cylinders, camshaft, and various mechanical parts. This allows for a clear understanding of the engine’s internal structure and operational mechanisms.
Observe the functioning of critical systems including the lubricating circuit, fuel system, and cooling system. The model’s electrical operation at 220 volts (110V US), running at a reduced speed, enables students to closely monitor and analyze the movement and interaction of mechanical parts.
The engine is professionally painted in different colors to differentiate parts and systems, enhancing visual learning and aiding in the comprehension of complex engine assemblies.
Engage with the engine’s mechanical operation, understanding the principles of the Common Rail system and its impact on fuel delivery and engine performance. Students can interact with the model to observe real-time changes and responses in engine behavior.

Value for Instructors

Utilize the sectioned engine as a dynamic teaching aid for demonstrating the operation and function of key engine components and systems. Ideal for explaining complex mechanical and fuel systems.
Uses OEM components for easy, safe, and realistic training that mimics real car.
The engine operates electrically at a reduced speed, ensuring a safe learning environment while providing a clear view of mechanical processes. This setup allows for effective teaching without the need for running a full-scale engine.
The use of color-coded sections and exposed internal components facilitates a better understanding of engine assemblies and their interactions, making it easier to convey complex concepts to students.
Mounted on a sturdy stand with wheels, the model is easy to position and integrate into various classroom setups, supporting a flexible teaching approach and enhancing classroom mobility.
