Truck Trailer Refrigeration system training stand MSTRREF01

AutoEDU

Product number: MSTRREF01

ASE category: A7

Fully functional truck trailer refrigeration system replicates the standard refrigeration unit found on truck trailers, featuring an internal combustion engine, a 400V electrical motor, and both cooling and heating capabilities. Mounted on a durable frame with casters for mobility, this training stand includes a comprehensive control panel and diagnostic socket for real-time system analysis and adjustments.

Request a quote

Check our catalog and product data sheet

Features

Fully functional refrigeration system with cooling and heating capabilities, powered by a diesel engine and a 400V electrical motor.
Allows for precise adjustments of system settings and temperature modes via remote control.
Equipped with a diagnostic connector for advanced system analysis and troubleshooting.
Mounted on a sturdy frame with four casters for easy movement and positioning in the classroom.
Ensure safe operation with accessible components protected by removable covers.
Features sensors for temperature monitoring, fuel level indication, and system diagnostics.

Value for Students

Fully functional truck trailer refrigeration system, including both cooling and heating operations.
Study and analyze key components such as the refrigerator, condenser, compressor, control panel, and diagnostic connector.
Use the diagnostic socket to perform system diagnostics, fault detection, and troubleshooting using advanced tools.
Understand the integration of a 400V electrical motor with a diesel engine, examining the power sources and their interactions.
Learn to control and adjust temperature settings using the remote control, exploring the principles of thermal management in refrigeration.
Study the fuel system, including the 12V battery and diesel fuel tank, with an emphasis on monitoring and maintaining fuel levels using the level indicator.

Value for Instructors

Provide students with a realistic, hands-on learning experience using OEM components.
Ensure safe and convenient access to all components with protective covers and a mobile stand, allowing for easy integration into the classroom environment.
Facilitate in-depth understanding of refrigeration technology and diagnostic procedures through interactive demonstrations and real-time data analysis.
The mobile and compact design allows for easy setup and integration into classroom settings, promoting efficient use of space and resources.
Board on castors version, which is mobile and space saving in the classroom, allows concurrent use by multiple students, promoting collaborative learning and practical training opportunities.
The training stand is designed for simplicity, requiring only small adjustments to reset to default parameters, making it easy to prepare and start each lesson quickly and efficiently.

Specifications

Dimensions: 2070 x 1300 x 2500 mm (81.50 in x 51.18 in x 98.43 in)
Weight: Approx. 1050 kg ( 2315 lb)
Power Sources: 12V battery for internal combustion engine; 400V, 3-phase, 32A household electrical network
Fuel type: Diesel
Components: Stand frame, refrigerator, condenser, control panel, diagnostic connector, compressor, 400V plug, diesel engine, electrical panel, exhaust pipe, 12V battery, fuel tank, transport wheels with brakes
Product number: MSTRREF01

Optional equipment (sold separately)

Diagnostic oscilloscope TEXA uniprobe
Automotive Diagnostics Kit ADK5004D TiePie
Diagnostic oscilloscope Foxwell Oscilloscope OS100
