Turbo-Intercooler Cutaway Educational Trainer AE410450M

Home

Cutaway Models - Engines, Gearboxes & Drivetrain

AutoEDU

Product number: AE410450M

ASE category: A1

Sectioned turbo-supercharger including compressor and turbine housings.
Visible waste-gate valve and internal bypass channel.
Lubrication circuit represented in cutaway.
Cutaway air-to-air intercooler with detailed internal air path.
Flexible connection hose between turbo and intercooler.

Request a quote

Check our catalog and product data sheet

Download the Full AutoEDU Product Catalogue

Enter your details to receive the AutoEDU catalogue with automotive training systems, laboratory equipment, technical specifications, and solutions for universities, technical colleges, and training centers.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Description

Manual turbocharger and intercooler cutaway trainer for automotive education. Includes a sectioned turbo-supercharger with centrifugal compressor, exhaust gas turbine, and waste-gate valve. Integrated air-to-air intercooler with visible internal airflow channels.

Specifications

Product type: Turbo-supercharger and intercooler cutaway trainer.
Components included: Turbocharger, waste-gate valve, lubrication circuit, air-air intercooler, flexible ducting.
Weight: 12 kg (26.46 lbs).
Dimensions: 600 × 400 × 400 mm (23.62 × 15.75 × 15.75 in).
Product number: AE410450M

Value for Students

Understand forced induction principles through direct observation of a centrifugal turbocharger.
Analyze turbine operation using exhaust gas energy to drive compressor blades.
Study the waste-gate valve’s role in controlling boost pressure and exhaust bypass.
Inspect internal compressor structure: impeller, housing, and oil lubrication passages.
Learn how air temperature is reduced in the intercooler before intake.
Identify airflow routing from intake, through compressor, into intercooler, and into engine.
Gain practical understanding of energy transformation from exhaust heat to compressed intake air.

Value for Instructors

Clear visibility of cutaway sections for classroom explanation.
Ready-to-use educational tool for demonstrating turbocharging principles.
Ideal for integration into automotive learning curriculum at vocational and technical levels.
