16 valve Chrysler turbo diesel CR engine with intercooler Cutaway AE36010E

AutoEDU

Product number: AE36010E

ASE category: A1

16-valve turbo diesel engine with a 4-stroke, 4-cylinder configuration, delivering 150-170 hp at 4000 RPM. It incorporates a Common Rail direct injection system with electro-injectors, controlled by an ECU, and a turbo-supercharger with an air-air intercooler for enhanced performance. This model operates electrically at 220V (110V US) with reduced speed, allowing detailed observation of components such as the twin overhead camshaft (DOHC) with a timing belt, vibration-damping balancing shafts, and essential systems like the alternator, oil filter, and oil pump.

Request a quote

Check our catalog and product data sheet

Download Catalogue

Data Sheet

Features

16-valve turbo diesel engine features a 4-stroke, 4-cylinder engine with 4 valves per cylinder, and a displacement of 2500/2800 cu. cm.
Common rail direct injection system equipped with electro-injectors controlled by an ECU, providing a detailed view of high-pressure fuel injection technology.
Turbo-supercharger with air-air intercooler demonstrates the enhancement of engine performance through forced air induction and cooling.
Cutaway design exposes internal components such as the twin overhead camshaft (DOHC), timing belt, vibration-damping balancing shafts, and more for detailed study.
Uses OEM components for easy, safe, and realistic training that mimics real car.
Operated manually through a crank handle for detailed examination at a controlled pace.

Value for Students

Study the workings of the Common Rail direct injection system, including the electronic control unit (ECU) and associated sensors. By observing how high-pressure fuel is injected into the combustion chamber, students gain practical knowledge of fuel atomization, injection timing, and the influence of engine speed on fuel delivery.
Students will explore the mechanics of turbo-supercharging with an air-air intercooler, gaining insights into how increased air pressure improves engine efficiency and power output.
The cutaway model exposes critical engine components, such as the twin overhead camshaft (DOHC) with a timing belt, vibration-damping balancing shafts, and the operation of electro-injectors. This visibility enables a thorough examination of the internal mechanics of a 4-stroke, 4-cylinder engine with 4 valves per cylinder.
Operating at a reduced speed with a 220V electrical power supply, this model allows students to safely observe the dynamic operation of the engine’s moving parts, making it easier to grasp complex mechanical interactions.

Value for Instructors

Effectively demonstrate OEM diesel engine technology, including the critical aspects of the Common Rail injection system, turbo-supercharging, and electronic fuel management.
The model’s design, featuring color-coded and chromed components, helps teachers guide students through the engine’s operational principles, ensuring clear and effective learning experiences.
The trainer is mounted on a sturdy stand with wheels, allowing for easy movement and integration into various classroom settings, making it a versatile educational tool.
With its electrical operation and manual crank handle, resetting the model for new lessons is straightforward, reducing preparation time and increasing instructional efficiency.

Specifications

Dimensions: 900 x 900 x 1200 mm (35.43 in×35.43 in×47.24 in)
Weight: 200 kg (440 lb)
Product number: AE36010E
