4 cylinder FWD diesel engine with clutch and gearbox cutaway AE36068E

AutoEDU

Product number: AE36068E

ASE category: A1

4-stroke, 4-cylinder inline diesel engine with indirect injection and a VE Bosch rotary injection pump. The engine includes an overhead camshaft, toothed belt distribution, single-plate clutch, 5-speed gearbox with reverse and differential, together with an alternator and thermostatic valve. The cutaway design highlights key systems, such as lubrication, fuel, and cooling. It operates electrically at 220 V ( 110 V), running at a reduced speed to allow observation of mechanical part operations.

Request a quote

Check our catalog and product data sheet

Download the Full AutoEDU Product Catalogue

Enter your details to receive the AutoEDU catalogue with automotive training systems, laboratory equipment, technical specifications, and solutions for universities, technical colleges, and training centers.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Features

4-stroke, 4-cylinder inline diesel engine with indirect injection and VE Bosch rotary injection pump.
Overhead camshaft with toothed belt distribution for timing operations.
Electrically powered at 220 V (110 V) with reduced operational speed for safe observation.
Single-plate clutch with diaphragm and 5-speed gearbox including reverse and differential.
Cross-sections highlighting lubrication, cooling, and fuel systems with color-coded parts.
Chrome-plated and galvanized components for enhanced durability and corrosion resistance.
Mounted on a wheeled stand for easy transportation and positioning.

Value for Students

Analyze engine operation, including the interplay of the camshaft, clutch, and gearbox, for a clear understanding of mechanical principles.
Provides insights into the function of a VE Bosch rotary injection pump and indirect fuel injection systems, teaching fuel delivery and combustion principles.
Highlights lubrication and cooling system pathways using colored sections and cross-sections, improving system understanding.
Identify and explain diesel engine components such as the camshaft, thermostatic valve, and alternator.
Demonstrates gear ratios, clutch engagement, and differential function, essential for automotive repair and diagnostics training.

Value for Instructors

Simplifies teaching with an electrically driven engine that operates at a reduced speed, providing a safe and controlled learning environment.
Supports detailed demonstrations of diesel engine mechanics, fuel systems, and gear operation.
Visually differentiated cutaway model with professional painting, allowing easy identification of components and circuits.
Durable construction with chromed and galvanized parts ensures long-term use for multiple teaching cycles.
Mobile and space saving in the classroom, allows concurrent use by multiple students.
Uses OEM components for easy, safe, and realistic training that mimics real car.

Specifications

Dimensions: 1300 x 860 x 1000 mm (51.18 x 33.86 x 39.37 in)
Weight: 140 kg (308 lbs)
Product number: AE36068E
