Diesel engine with rear wheel drive chassis cutaway educational trainer AE36150E

AutoEDU

Product number: AE36150E

Trainer built on a Fiat chassis, featuring a 4-stroke, 4-cylinder in-line diesel engine with a displacement of 1700 cm³, and a 5-speed gearbox with reverse. The model includes a rear-wheel drive system, a single-plate clutch with a diaphragm, and a propeller shaft with mechanical and flexible joints. It is equipped with a hypoid differential, a double circuit brake system with front disc and rear drum brakes, and a rear leaf spring suspension along with McPherson suspension in the front. The rack steering gear completes the functional layout. The trainer is mounted on a mobile stand with exposed sections for detailed examination of engine, lubrication, fuel, and cooling systems.

Request a quote

Download AutoEDU catalog and product datasheet

Features

Cutaway view displays camshaft, valves, cylinders, crankshaft, oil carter, and water cooling pump with visible lubrication and cooling circuits for functional study.
Visible vehicle chassis, includes rear leaf spring suspension, McPherson front suspension, shock absorbers, and subframe for suspension dynamics.
Rack steering gear for studying mechanical steering operation.
Disk and drum brakes, hand brake, pedal, hydraulic pump, and cylinder for hydraulic braking operation.
Visible gearbox gears, flywheel, clutch, shifting mechanism, and pedal for transmission and clutch study.
Color-coded components for Clear identification of systems (lubrication, cooling, suspension, braking) with color-coding for enhanced learning.

Value for Students

Detail understanding of the 4-stroke, 4-cylinder diesel engine, allowing study of internal combustion processes and the role of mechanical and fuel systems.
Enables hands-on learning in diagnosing and troubleshooting common engine issues, with a focus on understanding mechanical drivetrains, rear-wheel drive mechanics, and clutch operation.
Facilitates the study of hydraulic brake systems, including a double circuit with servo assistance, front-disc, and rear-drum brakes, allowing students to grasp the principles of brake operation, force distribution, and safety protocols.

Value for Instructors

Provides a fully operational cutaway model, enabling clear demonstrations of engine and chassis operations, which aids in effectively conveying complex automotive principles to students.
Built with galvanized and chromium-plated parts, this trainer ensures long-term durability and consistent performance, minimizing maintenance requirements and maximizing instructional time.
The color-coded and professionally painted components help teachers clearly differentiate between systems, improving the educational impact of each session.
Mounted on a mobile stand with wheels, the trainer is easy to position and integrate into various classroom setups, facilitating interactive and collaborative learning.
Requires small adjustments to reset to default parameters, making it easy to prepare and start each lesson.
Uses OEM components for easy, safe, and realistic training that mimics real car.

Specifications

Dimensions: 2200 x 1600 x 1150 mm (86.61 in x 62.99 in x 45.28 in)
Weight: approx. 420 kg (925 lb)
Power supply: operates at 220 volts (110V US), with an electrically driven engine for reduced-speed operation
Product number: AE36150E
