Brake and Suspension Cutaway Educational Trainer AE412060S

AutoEDU

Product number: AE412060S

ASE category: A5

Integrated disc brake with caliper and hydraulic lines.
Cross-sectioned drum brake showing internal mechanism.
Visible hydraulic double brake master cylinder.
McPherson strut assembly with spring and damper.
Rear damper component with full structure visibility.
Mounted on rigid wall panel for easy installation and use.
Designed for static demonstration and educational use only.

Request a quote

Check our catalog and product data sheet

Download the Full AutoEDU Product Catalogue

Enter your details to receive the AutoEDU catalogue with automotive training systems, laboratory equipment, technical specifications, and solutions for universities, technical colleges, and training centers.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Description

Wall-mounted training aid featuring real OEM automotive components for suspension and braking system instruction. Equipped with disc brake, drum brake, double brake master cylinder, rear hydraulic damper, and McPherson strut with spring. Provides a full overview of static hydraulic brake and suspension assemblies. Designed for mechanical and vocational training environments.

Specifications

Components included: Disc brake, drum brake, dual-circuit master cylinder, McPherson strut, rear damper.
Mount type: Vertical panel wall-mount.
Product weight: 30 kg (66.14 lbs).
Product dimensions: 1100 × 650 × 300 mm (43.31 × 25.59 × 11.81 in).
Product number: AE412060S

Value for Students

Learn static construction of hydraulic disc and drum braking systems.
Understand the internal layout of disc brake caliper and drum brake mechanism.
Study the working principle of double brake master cylinder with hydraulic fluid lines.
Identify key suspension components: McPherson strut, spring, damper, and rear shock absorber.
Explore force transfer in suspension and shock absorption behavior in passive setup.
Practice component recognition, inspection techniques, and system tracing.

Value for Instructors

Ready-to-use wall panel requires no setup or calibration.
Suitable for theoretical explanation and visual demonstration of hydraulic braking.
Supports explanation of dual circuit brake hydraulics.
Ideal for suspension layout teaching and part orientation.
Compact design fits all classroom sizes and levels.
Supports training in basic vehicle systems without electrical systems or moving parts.
