Cutaway throttle valve Educational Trainer AE513146S

Cutaway trainer with an exposed throttle valve assembly. Shows the airflow path, throttle plate, housing, shaft, and linkage. Designed as a static model for understanding throttle body operation in automotive intake systems.

• Type: mechanical cutaway trainer.
• Components: throttle housing, plate, shaft, bracket.
• Weight: 3 kg (6.61 lbs).
• Dimensions: 250 x 200 x 200 mm (9.84 x 7.87 x 7.87 in).
• Product number: AE513146S.

• Understand throttle valve mechanical construction and airflow control.
• Observe the cutaway design to see throttle plate position relative to airflow.
• Learn how throttle shaft rotation changes intake air volume.
• Identify key components: throttle plate, shaft, housing, mounting bracket.
• Visualize intake system airflow and mechanical control in real engines.
• Gain knowledge useful for further electronic throttle control system training.

• Useful for visual demonstrations of throttle body structure.
• Helps explain air intake control principles.
• Durable and compact for classroom or lab use.
• Easy to integrate into lectures on engine management systems.
• Supports basic and intermediate level automotive education topics.
