Cutaway water meter Educational Trainer AE513150S

Home

Cutaways

AutoEDU

Product number: AE513150S

Cutaway view of complete water meter.
Shows rotor, measurement gears, dial, inlet and outlet passages.
Real working parts exposed for functional understanding.

Request a quote

Check our catalog and product data sheet

Download Catalogue

Description

Cutaway Water Meter Educational Trainer training tool designed for demonstration of internal structure and fluid measurement principles in automotive and technical education. The trainer features a real water meter unit with visible cross-section for studying key components such as turbine rotor, measuring chamber, inlet and outlet flow passages, and mechanical counting mechanism.

Specifications

Product type: Cutaway mechanical water meter trainer.
Display: Cross-sectional internal components.
Weight: 2 kg (4.4 lbs).
Dimensions: 200 × 200 × 200 mm (7.87 × 7.87 × 7.87 in).
Product number: AE513150S

Value for Students

Understand how water meters measure flow through displacement or turbine rotation.
Learn component identification: rotor, chamber, impeller, dials, and gears.
Observe how mechanical counting tracks water volume.
Study flow direction and passage design for accurate flow control.
Gain practical knowledge useful in plumbing, fluid systems, and automotive cooling systems with flow sensors.
Improve mechanical inspection and fault identification skills through cross-section analysis.

Value for Instructors

Provides clear visual access to internal components for better explanation.
Enables passive demonstration without external systems or power.
Ideal for small group instruction and basic hydraulics overview.
Enhances hands-on learning in fluid systems and measurement units.
Suitable for introductory courses in automotive education and technical training.
