DSG Automatic transmission training stand MSATDSG01

AutoEDU

Product number: MSATDSG01

ASE category: A2

DSG Dual-Clutch Gearbox Educational Trainer offers an advanced tool for the comprehensive study and training of direct shift gearboxes (DSG). This highly detailed and fully functional training model is designed to provide students and instructors with a hands-on experience in understanding the construction, operation, settings, and adjustments of DSG systems.

Request a quote

Check our catalog and product data sheet

Download Catalogue

Data Sheet

Features

Fully functional DSG gearbox based on a dual-clutch system with six forward gears and one reverse gear, including standard “D” and sporty “S” drive modes.
Mechatronics module directly mounted to the gearbox, facilitating real-time control and gear shifting simulations.
OBD II diagnostic connector allows for fault code management, ECU identification, and live data monitoring.
Includes a STOP button and fuse block for immediate shutdown and safety during operation.
Electrohydraulic control system demonstrates the control of multi-disc clutches and gear shifting through an advanced electronic-hydraulic system.
Equipped with a manometer, dashboard, clutch control diagram, and gear selector, providing a comprehensive learning tool for students.
Plug and play design, requiring no additional mountings, assembly, or special preparation for operation.

Value for Students

Engage with a fully operational DSG gearbox, allowing in-depth exploration of the principles of operation, including the unique dual-clutch mechanism that combines the benefits of manual and automatic transmissions.
Learn to operate the DSG gearbox, including gear shifting controlled by an electronic-hydraulic system. Gain practical experience in diagnosing and troubleshooting using the OBD II diagnostic connector, monitoring real-time data, and managing fault codes.
Study the electrohydraulic system components and their roles in managing oil pressure and gear shifting, crucial for real-world applications.
Study the mechanical and electronic systems, including clutch control mechatronics, automatic gearbox operations, and the interworking of various sensors like G182, G501, and G502, providing a solid foundation for advanced automotive engineering.

Value for Instructors

Use the model to clearly demonstrate the construction, functionality, and troubleshooting of DSG systems.
Uses OEM components for easy, safe, and realistic training that mimics real car.
The model uses real DSG components, offering students a practical and realistic learning experience. The visible clutch control mechatronics and electric diagrams enhance the teaching process.
Easily reset and prepare the trainer for each session with minimal adjustments, ensuring smooth transitions between lessons. The robust construction and mobility of the training stand allow for convenient use in various classroom settings.
The integrated emergency stop system and protective features ensure a safe learning environment, enabling instructors to focus on teaching while minimizing risks.
Plug and play design, requiring no additional mountings, assembly, or special preparation for operation.

Specifications

Dimensions: 800 x 800 x 1650 mm (31.50 in×31.50 in×64.96 in)
Weight: approx. 150 kg (330 lb)
Power supply: 12V contacts available
Product number: MSATDSG01

Optional equipment (sold separately)

Diagnostic scan tool OBDEleven (depends on model)
Diagnostic scan tool VCDS (depends on model)
Diagnostic scan tool TXT MULTIHUB CAR
Diagnostic scan tool AutoCOM ICON
Diagnostic scan tool NANO S TEXA
Diagnostic oscilloscope TEXA uniprobe
Diagnostic oscilloscope Automotive Diagnostics Kit ADK5004D TiePie
Diagnostic oscilloscope Foxwell Oscilloscope OS100
