Automatic Transmission Cutaway Educational Trainer AE411040M

AutoEDU

Product number: AE411040M

ASE category: A2

Automatic transmission cutaway educational trainer features a hydraulic torque converter, epicyclic gear system with 3 forward speeds plus reverse, and multiple-plate clutches. Operated manually via a handwheel, it demonstrates key components such as control valves, planetary gears, and clutch disks, providing an in-depth understanding of automatic transmission mechanics. The model includes a hydraulic oil pump and requires routine lubrication for optimal performance, offering students a practical experience in servicing and maintaining transmission systems.

Request a quote

Check our catalog and product data sheet

Features

Hydraulic torque converter simulates real-world torque transmission and fluid coupling in automatic gear systems.
Epicyclic gear system with 3 forward speeds and reverse gear for realistic gear shift simulation and hands-on operation.
Multiple-plate clutches demonstrate the mechanics behind clutch engagement and disengagement during operation.
Manually operated handwheel for practical demonstration of transmission components in motion.
Mounted on a mobile stand with wheels for ease of use and movement in educational environments.

Value for Students

Automatic transmission system including hydraulic converters, planetary gears, and multiple-plate clutches.
3-speed forward and reverse epicyclic gear, crucial for learning key concepts of torque conversion, power transmission, and gear shifting.
Understand control valves and their role in managing hydraulic pressure, simulating real-world scenarios of automatic transmission operations.
Practice manual operation of the transmission system through the hand-crank mechanism applied to the torque converter, reinforcing theoretical knowledge with practical experience.
Study the lubrication and servicing requirements of moving transmission parts, such as crown wheels, clutch disks, and planetary gears.
Explore the components of the transmission, including clutch disks, crown wheels, and the hydraulic torque converter, enhancing knowledge of how each part interacts within the system.

Value for Instructors

Detailed cutaway model of an automatic transmission, ideal for demonstrating the internal operations and structure to students.
Allows easy operation via the handwheel, enabling teachers to manually showcase how different gears and clutches engage during gear changes.
Facilitates safe, controlled learning with clearly visible parts, aiding in the step-by-step explanation of transmission mechanics, gear ratios, and torque conversion.
Durable, mobile design allows for flexibility in classroom setup, making it easy to transport and integrate into various training environments.
Supports collaborative learning, allowing multiple students to engage with the model at once.

Specifications

Dimensions: 1000 x 650 x 700 mm (39.37 in×25.59 in×27.56 in)
Weight: 70 kg (155 lb)
Key Components: Hydraulic converter, epicyclic gear, multiple-plate clutches, control valves, hydraulic oil pump, planetary gear system.
Operation: Manually operated via handwheel.
Product number: AE411040M
