Hydraulic/Pneumatic Ball Valve Cutaway AE513120S

Home

Cutaway Models - Engines, Gearboxes & Drivetrain

AutoEDU

Product number: AE513120S

Industrial-grade ball valve cutaway for educational use.
Shows actuator mechanism, ball shaft, seals, and fluid passages.
Manual rotation display of ball valve functionality.

Request a quote

Check our catalog and product data sheet

Download the Full AutoEDU Product Catalogue

Enter your details to receive the AutoEDU catalogue with automotive training systems, laboratory equipment, technical specifications, and solutions for universities, technical colleges, and training centers.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Description

Educational training model showing the internal structure and working principle of a hydraulic and pneumatic ball valve. Cutaway section clearly exposes all functional areas including actuator, shaft, ball element, seals, and valve body. The trainer is mounted on a stable metallic base for safe use in classroom or laboratory conditions. Ideal tool for practical training in fluid mechanics and automation control systems.

Specifications

Product type: Cutaway hydraulic/pneumatic ball valve educational trainer.
Material: Industrial valve body with aluminum and steel components.
Cutaway: Precision-machined cross-section showing all internal parts.
Dimensions: 200 x 250 x 300 mm (7.87 x 9.84 x 11.81 in).
Weight: 5 kg (11.02 lbs).
Product number: AE513120S.
