Petrol (gasoline) Engine Feeding Circuit Cutaway AE510350S

AutoEDU

Product number: AE510350S

ASE category: A1

Sectioned float-type fuel tank with integrated level gauge.
Visible diaphragm fuel pump for low-pressure mechanical fuel transfer.
Cutaway single-body carburettor illustrating mixture formation.
Inlet manifold connected to carburettor, showing airflow path.

Request a quote

Check our catalog and product data sheet

Download Catalogue

Description

Educational trainer designed to demonstrate the petrol (gasoline) engine feeding circuit system. Built with a real float-type fuel tank featuring level gauge, diaphragm fuel pump, single-body carburettor, and an intake manifold. All components are sectioned for visibility and understanding.

Specifications

Components: Float fuel tank with level sensor, diaphragm fuel pump, single-body carburettor, inlet manifold.
Weight: 3 kg (6.6 lbs).
Dimensions: 400 x 300 x 300 mm (15.75 x 11.81 x 11.81 in).
Product number: AE510350S

Value for Students

Learn fuel delivery system components: float chamber, diaphragm pump, carburettor, and inlet manifold.
Understand how petrol (gasoline) travels from the tank through the pump to the carburettor and into the intake system.
Observe sectioned internal parts to identify and study mechanical layout and fuel flow paths.
Gain knowledge of float-based fuel level measurement and carburettor operation principles.
Understand mechanical diaphragm pump working principle used in low-pressure petrol (gasoline) delivery.
Study single-body carburettor structure and its role in air-fuel mixture formation.

Value for Instructors

Easy-to-use automotive training aid for demonstrating petrol (gasoline) engine feeding system without active fuel circulation.
Visual cross-section simplifies explanation of fuel flow, air-fuel mixing, and carburettor mechanics.
Safe, clean platform to show components without fuel use or engine operation.
