Single-cylinder 4-stroke diesel engine air cooled AE38920F

AutoEDU

Product number: AE38920F

ASE category: A1

Fully functional automotive education tool includes a single-cylinder, 4-stroke diesel engine with direct fuel injection and forced air cooling. The engine features a 211 cc displacement, a mechanical in-line injection pump, and develops 3.8 hp at 3000 rpm. It is equipped with a manual recoil starting system, camshaft positioned in the crankcase, and overhead valve (OHV) configuration. Mounted on a steel frame with vibration isolators, this automotive training aid is designed for hands-on mechanical and fuel system training in educational environments.

Request a quote

Check our catalog and product data sheet

Download Catalogue

Features

Real working 4-stroke diesel engine.
Recoil manual start system.
Overhead valve configuration.
In-line mechanical fuel injection pump.
Forced air cooling with visible cooling fins.
Mounted on vibration-isolated frame for stability.
Visible components and layout for teaching purposes.

Specifications

Engine type: Single-cylinder 4-stroke diesel.
Displacement: 211 cc.
Power output: 3.8 hp at 3000 rpm.
Injection system: Direct injection with in-line pump.
Valve configuration: Overhead valves (OHV).
Camshaft: Located in crankcase.
Cooling system: Forced air.
Starting method: Manual recoil.
Mounting: Steel frame with vibration isolators.
Weight: 30 kg (66.1 lbs).
Dimensions: 500 x 500 x 600 mm (19.69 x 19.69 x 23.62 in).
Product number: AE38920F

Value for Students

Understand 4-stroke diesel engine operation cycle: intake, compression, power, exhaust.
Identify direct injection system components: in-line injection pump, injector, combustion chamber.
Learn air-cooling principles using forced airflow and heat dissipation through finned surfaces.
Observe mechanical timing system: camshaft in crankcase and OHV actuation.
Practice manual engine startup using recoil ignition system.
Analyze combustion process and fuel delivery characteristics of small displacement diesel engines.
Gain skills in basic maintenance, mechanical inspection, and functional testing.

Value for Instructors

Reliable demonstration of diesel engine components and working principles.
Allows safe, hands-on explanation of direct fuel injection operation.
Suitable for basic to intermediate mechanical engine training.
Stable, portable trainer designed for repeated classroom use.
Enables real-time observation of start-up, cooling, and valve actuation processes.
Clear visibility of system layout for instructional explanations.
