TOYOTA LEXUS V8 Engine Cutaway AE35178M

Manual automotive training tool with visible internal mechanical structure. Features 8-cylinder V-type petrol (gasoline) engine with DOHC layout, 32 valves, electronic ignition, and multi-point injection system. Engine is manually rotated using crank handle to demonstrate component motion. Cross-section reveals internal working parts including valve train, piston assembly, cooling and lubrication flow channels. Mounted on mobile stand for classroom use in automotive education environments.

• Engine type: 8-cylinder V-type petrol (gasoline).
• Displacement: 3968 cc.
• Valvetrain: DOHC, 4 valves per cylinder.
• Bore x stroke: 87.5 x 82.5 mm.
• Compression ratio: 10:1.
• Fuel system: Multi-point electronic injection.
• Ignition: Electronic.
• Alternator: 12V type.
• Cooling: Centrifugal water pump system.
• Operation: Manual crank rotation.
• Mounting: Mobile stand with wheels.
• Weight: 180 kg (396.8 lbs).
• Dimensions: 1000 x 900 x 1500 mm (39.37 x 35.43 x 59.06 in).
• Product number: AE35178M

• Learn engine configuration and combustion principles of 8-cylinder V-type petrol (gasoline) engine.
• Understand valve timing through DOHC layout with 4 valves per cylinder (total 32 valves).
• Manually rotate crankshaft to observe piston movement, valve actuation, and camshaft operation.
• Visualize internal component interaction: pistons, connecting rods, crankshaft, camshafts, valves, rocker arms.
• Identify multi-point fuel injection system components and their location.
• Recognize electronic ignition system layout, including distributor-less ignition concept.
• Study cooling system design with centrifugal water pump operation.
• Inspect alternator function and drive belt layout.
• Reinforce learning in engine mechanics, fuel systems, and ignition principles.

• Easy to demonstrate 4-stroke cycle mechanics in physical, visual way.
• Stable, mobile design suitable for classroom demonstrations and exams.
• Enables safe, hands-on instruction without need for live fuel or ignition.
• Helps teach combustion, mechanical timing, injection and lubrication in one unit.
• Enhances understanding for learners of all levels with real engine structure.
