Description

Educational trainer featuring a sectioned commercial truck fuel filter assembly. Internal construction includes multi-layer pleated paper filter element, integrated bypass valve, inlet/outlet ports with threaded fittings, and pressure-resistant metal housing. Cutaway model reveals full cross-section of filter chamber, fluid flow paths, sealing components, and bypass valve mechanism.

Specifications

Product type: Truck fuel filter cutaway trainer.
Filter type: Diesel fuel filter with integrated bypass valve.
Components visible: Filter element, housing, bypass valve, inlet/outlet ports, seals.
Product number: AESKF01

Value for Students

Understand fuel filtration in diesel engines by examining filter media and flow direction.
Learn how fuel enters through inlet port, passes through the filter paper, and exits via outlet port.
Observe internal structure: bypass valve, return spring, sealing rings, filter housing, and threaded ports.
Identify signs of common wear or failure, including seal damage or clogging.
