Wiring trouble-shooting system (conventional coil ignition) AE49990E

Compact electrical system training bench designed for 12V automotive education. All essential components of a conventional coil ignition system are mounted on a stable frame. Includes working lighting, signaling, ignition, and charging circuits. Red and black wire couplings allow clear polarity distinction for safe circuit connection and fault diagnostics. Enables manual assembly and disassembly of electrical subsystems for comprehensive automotive training.

• System type: 12V automotive electrical and ignition system.
• Components included: Front/rear lights, turn signals, emergency flasher, license light, horn, wiper motor, instrument panel, battery, distributor, ignition coil, spark plugs, starter motor, alternator, voltage regulator, fuse box.
• Wiring: 19x positive wires with red couplings, 10x negative wires with black couplings.
• Mounting: Fixed on metallic stand.
• Weight: 90 kg (198.4 lbs).
• Dimensions: 550 x 1950 x 2050 mm (21.7 x 76.8 x 80.7 in).
• Product number: AE49990E

• Learn complete 12V car wiring system including lights, wipers, horn, ignition, and starting system.
• Identify and connect system components using colored wire couplings: red (positive), black (negative).
• Understand function of battery ignition, spark plug firing, coil operation, and distributor timing.
• Practice diagnostics and fault-finding procedures with instructor-inserted connection faults.
• Gain hands-on experience with real automotive components: fuse box, alternator, voltage regulator, and starter motor.
• Assemble and disassemble systems for better understanding of automotive electrical layouts.
• Study how mechanical motion from engine is converted into electrical energy by alternator.
• Observe interaction between control switches and output components like lights and horn.

• Practical automotive training aid for electrical system demonstrations.
• Safe, controlled 12V working environment.
• Allows instructors to pre-set faults for student diagnostics training.
• Easy-to-observe layout for group teaching and demonstrations.
• All components fixed on panel—no loose wiring or unstable parts.
• Effective for teaching circuit logic, component function, and system integration.
• Ideal tool for entry-level automotive education in schools and colleges.
