6-cylinder Petrol (Gasoline) DOCH Engine Cutaway AE35195M

Cutaway model of a V6 petrol engine with multipoint electronic injection system. Equipped with dual overhead camshafts (DOHC) on each cylinder head, centrifugal water pump, and 12 V alternator. Cross-section reveals complete internal fuel, air, cooling, and lubrication systems. Manual crank handle allows full visual demonstration of internal engine movement. Designed for hands-on automotive education and technical training.

• Engine type: 6-cylinder V petrol (gasoline) engine.
• Displacement: 2000–3000 cm³.
• Camshaft: DOHC (2 per head).
• Injection system: Multipoint electronic.
• Cooling: Centrifugal water pump.
• Electrical system: 12 V alternator.
• Operation: Manual crank handle.
• Construction: Sectioned cutaway model.
• Dimensions: 1200 x 600 x 1000 mm (47.24 x 23.62 x 39.37 in).
• Weight: 190 kg (418.9 lbs).
• Product number: AE35195M

• Learn combustion cycle stages in a 6-cylinder V-engine: intake, compression, power, exhaust.
• Understand V-engine layout and dual overhead camshaft (DOHC) configuration.
• Identify components and flow paths of multipoint electronic injection system.
• Observe working principles of centrifugal water pump in cooling circuit.
• Recognize alternator function in engine electrical system.
• Study interaction of pistons, valves, and camshafts by rotating crank manually.
• Visualize lubrication and cooling channels in real engine structure.

• Clear visibility of sectioned engine components for classroom demonstrations.
• Manual crank feature shows engine timing and motion.
• Ideal for vocational schools, technical colleges, and university labs.
• Supports a wide range of mechanical training topics.
• Reliable automotive training aid for both beginners and advanced students.
