6 V Cylinders Petrol (Gasoline) Engine Carburettor Cutaway AE35190E

Educational trainer with 6 V-type petrol (gasoline) engine, overhead camshaft (OHC) system, twin-body carburettor, centrifugal water pump, 12 V alternator, and membrane clutch. The engine is sectioned for training use with visible cross-sections of the combustion chambers, cooling system, lubrication circuits, and fuel system. Trainer operates electrically at 220 V with reduced RPM for safe, slow-speed mechanical observation. All critical components are chrome-plated or galvanized for durability. Mounted on a wheeled stand for mobility in classroom environments.

• Engine type: 4-stroke V6 petrol (gasoline) engine.
• Cylinder configuration: V-type, 6 cylinders.
• Displacement: 2800–3200 cm³.
• Camshaft type: Overhead camshaft (OHC).
• Fuel system: Twin-body carburettor.
• Cooling system: Centrifugal water pump.
• Electrical system: 12 V alternator.
• Clutch: Membrane clutch.
• Operation: Electric motor, 220 V power input.
• Stand: Mobile frame with wheels.
• Material finish: Painted, chrome-plated, and galvanized components.
• Weight: 190 kg (418.88 lbs).
• Dimensions: 1200 × 600 × 1000 mm (47.24 × 23.62 × 39.37 in).
• Product number: AE35190E

• Observe mechanical movement of pistons, camshafts, crankshaft, valves, and flywheel during low-speed operation.
• Understand fuel intake and air-fuel mixing principles using visible twin-body carburettor system.
• Learn function of centrifugal water pump in engine cooling process.
• Identify complete overhead camshaft operation per cylinder head.
• Study lubrication flow, oil channels, and crankcase oiling method.
• Recognize membrane clutch engagement and disengagement mechanism.
• Inspect full electrical alternator function and voltage generation in 12 V systems.
• Analyze V-type cylinder layout and differences in combustion chamber design.
• Practice visual fault diagnosis and component recognition for automotive training.

• Clear visualization of all internal engine functions for simplified demonstrations.
• Safe electric-powered system with reduced speed prevents risk during operation.
• Suitable for multiple automotive education levels, from beginners to advanced.
• Easy integration into classroom or workshop due to mobile stand on wheels.
• Optimized for use in lessons covering internal combustion, cooling, fuel, and electrical systems.
• Supports hands-on teaching of mechanical concepts without need for live fuel ignition.
