Air conditioning and climate control Educational Trainer MSC01

AutoEDU

Product number: MSC01

ASE category: A7

Fully operational air conditioning and climate control training board designed for in-depth technical education. This trainer includes an integrated electronic climate control system (Climatronic) with an orifice tube, utilizing OEM Audi/VW components. The system operates with R134a refrigerant and allows real-time monitoring of airflow flaps, compressor function, pressure distribution, and climate control parameters. Equipped with an OBD 16-pin diagnostic connector, it supports fault simulations and electrical measurements. The unit is securely installed in a mobile aluminum frame for classroom use.

Request a quote

Check our catalog and product data sheet

Download Catalogue

Features

Fully functional climate control system with Climatronic integration.
R134a refrigerant-based system with pressure gauges for high/low circuit monitoring.
Visible HVAC compressor with electromagnetic clutch and airflow flap mechanisms.
Built-in electrical wiring diagram with banana plug jumpers for safe measurement and circuit testing.
Integrated voltmeter for real-time monitoring of sensor and actuator signals.
OBD 16-pin diagnostic port for ECU communication, fault simulation, and data analysis.
Manual and automated fault code reading and system parameter display.
Real-time visualization of temperature changes and airflow dynamics.
Secure, mobile aluminum frame structure.

Value for Students

Provides hands-on experience with a complete electronic air conditioning system, allowing students to study airflow control, refrigerant pressure changes, and climate regulation.
Enables real-time diagnostics using OBD scan tools to read/erase fault codes, identify ECU data, and analyze live sensor readings.
Supports practical training in electrical signal measurement with a built-in voltmeter and banana plug connectors, allowing students to test potentiometers, temperature sensors, and control motors.
Allows simulation of over 15 system faults, helping students understand common air conditioning failures and troubleshooting methods.
Teaches airflow management by visualizing the operation of HVAC components, including air recirculation, footwell, and defrost modes.
Demonstrates temperature variation and refrigerant pressure behavior under different operational conditions.

Value for Instructors

Uses OEM components to provide realistic training scenarios that mimic real automotive climate control systems.
Offers structured learning with fault simulation capabilities, enabling instructors to create problem-solving exercises.
Simplifies teaching with clear electrical diagrams and labeled sensors, facilitating easy explanation of system functionality.
Supports both manual and computer-based diagnostic procedures, allowing flexible teaching methods based on student expertise.
Mobile, plug-and-play design ensures easy setup and integration into different training environments.

Specifications

Power supply: 220V (110V US)
Refrigerant type: R134a
Fault simulations: 15+
Integrated sensors: G92, G114, G112, G113, G89, G191, G192, G17
Diagnostic connection: OBD 16-pin
Measurement tools: Built-in voltmeter, optional oscilloscope and diagnostic scan tool
Dimensions: 1680 x 800 x 500 mm (66.14 x 31.50 x 19.69 in)
Weight: Approx. 100 kg (220.46 lb)
Product number: MSC01

Optional equipment (sold separately)

Air conditioning recharge station A/C recharge station ECK NEXT R134a
Air conditioning recharge station A/C Air Conditioning Recharge Station KONFORT 705R Z10410
Diagnoistic scan tool TXT MULTIHUB CAR
Diagnoistic scan tool AutoCOM ICON
Diagnoistic scan tool NANO S TEXA
Diagnoistic scan tool VCDS HEX-NET Pro
Diagnoistic oscilloscope TEXA uniprobe
Diagnoistic oscilloscope Automotive Diagnostics Kit ADK5004D TiePie
Diagnoistic oscilloscope Foxwell Oscilloscope OS100
