Alternator Double-flow Cooling Cutaway Educational Trainer AE410081M

AutoEDU

Product number: AE410081M

ASE category: A6

Cutaway model of a dual-flow cooling alternator made from OEM automotive components. Internal structure is fully visible, including rotor, stator, rectifier, brushes, slip rings, and integrated cooling fans. Designed for static display and technical analysis of alternator design and airflow cooling system.

Request a quote

Check our catalog and product data sheet

Features

Cutaway alternator with visible rotor, stator, rectifier, slip rings, brushes, and dual cooling fans.
Shows dual-path internal airflow system for thermal management.
Constructed from OEM automotive components for accuracy.
Static, non-powered unit for safe classroom analysis.
Mounted on fixed base for stable, 360° visual access.

Value for Students

Shows internal alternator structure: rotor, stator windings, rectifier diodes, brushes, and slip rings.
Explains electromagnetic induction and DC conversion using diode rectifier bridge.
Demonstrates double-flow air cooling paths for thermal load management during high RPM operation.
Supports identification of part layout and understanding of cooling design to prevent overheating.
Helps visualize alternator operation in vehicle charging systems.

Value for Instructors

OEM-based cross-section aids explanation of real-world alternator internals.
Clear layout supports teaching of energy conversion and cooling flow principles.
No electrical operation ensures safe use during close inspection and group lessons.
Ideal for technical demonstrations without setup or operational requirements.
