Automotive Electrical System and EV Training Equipment

Electronic ignition system Educational Trainer AE410010

AutoEDU

Product number: AE410010

ASE category: A1

Educational Trainer is designed to demonstrate the principles of a breakerless ignition system for a four-cylinder, four-stroke engine. Equipped with OEM vehicle components such as spark plugs, ignition distributor, and ignition coil, the trainer features a magnetic pulser integrated within the distributor to control coil current conduction. Key specifications include a spark risetime of 45 µs, a duration of 2 ms, and secondary high voltage of 28 kV. The system operates manually, providing hands-on learning while maintaining a constant spark energy, even under low battery voltage conditions.

Request a quote

Check our catalog and product data sheet

Download the Full AutoEDU Product Catalogue

Enter your details to receive the AutoEDU catalogue with automotive training systems, laboratory equipment, technical specifications, and solutions for universities, technical colleges, and training centers.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Download the Full Technical Data Sheet

Enter your details to receive the complete technical documentation for this AutoEDU training system, including product description, specifications, and key features for automotive training applications.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Features

Breakerless electronic ignition system for four-cylinder, four-stroke engines.
Components include spark plugs, ignition distributor, coil, and ignition wiring, all mounted on a visible plastic-plated wooden base.
Manual operation to demonstrate system functionality in a straightforward manner.
Integrated magnetic pulser replaces the traditional mechanical breaker, offering enhanced control of coil current conduction time.
The didactic panel allows static display and explanation of system components.
Constant spark energy achieved even with reduced battery voltage.

Value for Students

Learn the principles of breakerless electronic ignition systems, including the functionality of a magnetic pulser integrated within the ignition distributor.
Understand the process of coil current conduction and ignition phase signal processing, controlled electronically, independent of mechanical limitations.
Gain experience working with OEM components such as spark plugs, distributor, ignition coil, and ignition wiring.
Study the dynamics of spark energy control even under low battery conditions, a critical concept for automotive repair.
Hands-on experience with primary coil current control and analysis of how pulse signals adjust based on engine RPM.
Perform diagnostics on the system’s components, such as the electromagnetic pulse generator and centrifugal mechanical advance.
Learn critical spark parameters: risetime of 45 µs, spark duration of 2 ms, and secondary high voltage of 28 kV.

Value for Instructors

Offers an authentic demonstration of breakerless ignition systems using OEM vehicle components, giving students practical automotive skills.
Simple manual operation provides a clear understanding of ignition principles without complex automation.
Allows for hands-on learning, helping students recognize the nuances of the ignition phase signal, coil current conduction, and spark energy management.
The statically displayed system on a didactic panel facilitates easy breakdown and discussion of key ignition system concepts.
Durable and reliable build ensures long-lasting use for repeated classroom demonstrations and training sessions.

Specifications

Dimensions: 700 x 250 x 550 mm (27.56 in×9.84 in×21.65 in)
Weight: 10 kg (22 lb)
Product number: AE410010
