Automatic Transmission 5 Forward Speed + Reverse Cutaway Educational Model AE411042M

AutoEDU

Product number: AE411042M

ASE category: A2

Cutaway model of a 5-speed automatic transmission with reverse gear designed for automotive education. Exposes internal components including torque converter, planetary gear sets, multiple clutch packs, bands, oil pump, and hydraulic control circuits. Built as an automotive training aid for technical education programs.

Request a quote

Check our catalog and product data sheet

Features

Cutaway of full automatic 5-speed transmission with reverse.
Visible torque converter, clutch packs, planetary carriers, valve body.
Color-differentiated internal parts.
Stable mounting for classroom demonstrations.

Specifications

Transmission type: automatic, 5 forward speeds + 1 reverse.
Weight: 75 kg (165 lbs).
Dimensions: 1000 x 650 x 700 mm (39.37 x 25.59 x 27.56 in).
Product number: AE411042M

Value for Students

Identify torque converter function and internal fluid coupling principles.
Analyze planetary gear set operations for gear reduction and overdrive.
Understand hydraulic valve body operation controlling gear shifts.
Observe multi-plate clutch pack engagement and band application.
Learn oil circulation paths and cooling principles inside automatic transmissions.
Study reverse gear activation through planetary carrier re-routing.
Improve automotive learning with direct mechanical system observation.
