Direct Injection Piston Cutaway Educational Trainer AE410500S

AutoEDU

Product number: AE410500S

ASE category: A1

Real piston with precision cutaway design.
Shows injector placement in direct injection layout.
Highlights combustion chamber shape and piston head geometry.
Mounted on durable display base for classroom use.

Request a quote

Check our catalog and product data sheet

Download the Full AutoEDU Product Catalogue

Enter your details to receive the AutoEDU catalogue with automotive training systems, laboratory equipment, technical specifications, and solutions for universities, technical colleges, and training centers.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Description

Automotive educational trainer designed to demonstrate the operation of a direct injection piston system. The trainer features a real piston with a precision cutaway revealing the combustion chamber, injector location, valve areas, and cylinder wall interaction. This automotive training aid is suitable for use in classrooms, labs, and technical centers for hands-on visual learning. Built to support automotive education and training in fuel systems and internal combustion mechanics.

Specifications

Product type: Direct injection piston cutaway trainer.
Construction: Real engine piston with cutaway section.
Injection system type: Direct fuel injection.
Weight: 7 kg (15.43 lbs).
Dimensions: 180 x 180 x 350 mm (7.08 x 7.08 x 13.77 in).
Product number: AE410500S
