Indirect Injection Piston Cutaway Educational Model AE410510S

Cutaway Models - Engines, Gearboxes & Drivetrain

AutoEDU

Product number: AE410510S

ASE category: A1

Educational cutaway model of an indirect injection piston. Shows piston head shape, cooling channels, and structural design. Designed for automotive education, automotive training equipment, and automotive learning programs.

Request a quote

Check our catalog and product data sheet

Download the Full AutoEDU Product Catalogue

Enter your details to receive the AutoEDU catalogue with automotive training systems, laboratory equipment, technical specifications, and solutions for universities, technical colleges, and training centers.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Features

Cutaway view of piston crown, skirt, ring grooves, pin bore.
Real OEM material used for production pistons.
Compact, lightweight educational tool.

Specifications

Product type: Indirect injection piston cutaway model.
Material: Metal alloy (standard piston material).
Sections shown: Crown, skirt, grooves, pin bore.
Weight: 2.5 kg (5.51 lbs).
Dimensions: 120 x 120 x 220 mm (4.72 x 4.72 x 8.66 in).
Product number: AE410510S

Value for Students

Study piston design used in indirect injection engines.
Identify piston crown, skirt, ring grooves, and pin bore.
Understand material thickness and cooling channel positioning.
Learn about thermal stress areas and friction zones.
Practice basic visual inspection techniques.

Value for Instructors

Clear demonstration of indirect injection piston structure.
Durable and compact for classroom and workshop use.
Supports mechanical design explanation.
Easy to integrate into automotive education courses.
