Distributor Cutaway Educational Trainer AE410060M

Distributor Cutaway Educational Trainer AE410060M

AutoEDU
Product number: AE410060M
ASE category: A1
  • Cross-section view of mechanical distributor.
  • Hand crank mechanism for manual rotation.
  • Visible centrifugal advance mechanism.
  • Rotor, cap, breaker points and shaft exposed.
  • Uses OEM ignition system components.
Request a quote
Check our catalog and product data sheet

Description

Manual distributor cutaway trainer designed for educational use in automotive training. Constructed with a real distributor unit sectioned to reveal internal components such as centrifugal advance weights, ignition contact breaker, rotor arm, and distributor shaft. Manually operated by hand crank to simulate rotation. All components are original automotive parts mounted on a robust platform for repeated use.

Specifications

  • Weight: 7 kg (15.4 lbs).
  • Dimensions: 180 x 180 x 350 mm (7.1 x 7.1 x 13.8 in).
  • Product number: AE410060M.

Value for Students

  • Learn distributor ignition system working principles.
  • Understand mechanical ignition timing through centrifugal advance mechanism.
  • Observe contact breaker operation during shaft rotation.
  • Identify rotor arm and spark distribution channels.
  • Practice diagnosing common distributor faults in visual format.
  • Study internal component motion during manual rotation.
  • Strengthen understanding of ignition timing control.
  • Suitable for introductory automotive education classes.

Value for Instructors

  • Easy to demonstrate ignition principles without power supply.
  • Shows distributor working cycle clearly using real components.
  • Enables explanation of spark sequence and timing advance.
  • Safe and durable for repeated classroom use.
  • Useful for theoretical and hands-on training.
