Fiat petrol engine with multi-point electronic injection + gearbox cutaway AE35222IEE

Fiat petrol engine with multi-point electronic injection + gearbox cutaway AE35222IEE

AutoEDU
Product number: AE35222IEE
ASE category: A1
  • 4 in-line petrol (gasoline) engine with overhead camshaft (OHC).
  • Multi-point electronic fuel injection system.
  • Electronic ignition system.
  • Manual gearbox: 5 forward speeds + 1 reverse.
  • Integrated differential for full drivetrain understanding.
  • Transparent cutaway to reveal internal engine and gearbox components.
  • 220V (110V US)  electrical operation with reduced rotation speed.
Request a quote
Check our catalog and product data sheet

Description

Cutaway educational trainer features a 1250 cc 4-cylinder in-line Fiat petrol (gasoline) engine combined with a manual gearbox and differential. The engine is equipped with an overhead camshaft (OHC), multi-point electronic fuel injection system, and electronic ignition. It is powered electrically at 220V (110V US)  and runs at a reduced speed, allowing clear observation of internal mechanical parts and fuel injection operation. The gearbox is a 5-speed forward and reverse type. The unit is mounted on a stable frame for safe classroom demonstrations.

Specifications

  • Engine type: 4-cylinder inline petrol.
  • Displacement: 1250 cc.
  • Valve control: Overhead camshaft (OHC).
  • Fuel system: Multi-point electronic injection.
  • Ignition system: Electronic.
  • Transmission: Manual gearbox 5F + R with differential.
  • Operation: Electric motor, 220V (110V US) , reduced speed.
  • Weight: 90 kg (198.42 lbs).
  • Dimensions: 1200 x 700 x 1000 mm (47.24 x 27.56 x 39.37 in).
  • Product number: AE35222IEE

Value for Students

  • Understand internal operation of 4-cylinder in-line engine with OHC layout.
  • Learn multi-point electronic fuel injection system: fuel rail, injectors, intake manifold.
  • Identify electronic ignition system components: ignition coil, spark plug wires, distributor.
  • Study mechanical operation of 5-speed gearbox with reverse and integrated differential.
  • Observe piston movement, crankshaft rotation, valve timing and camshaft drive.
  • Learn function of fuel injection sensors and actuators in electronic control system.
  • Analyze synchronization between engine combustion and gear transmission.
  • Practice diagnostics by observing static and moving parts in cutaway layout.

Value for Instructors

  • Clear cutaway visibility for effective classroom demonstration.
  • Safe electric-powered display with reduced operating speed.
  • Ideal for teaching fuel injection and ignition system operation.
  • Allows step-by-step explanation of power transmission components.
  • Suitable for courses in automotive education, technical training, and vocational schools.
