Multi-Point Electronic Injection I.C. Engine Model Cutaway AE47490M

AutoEDU

Product number: AE47490M

ASE category: A1

This single-cylinder cutaway model features original components from a modern petrol (gasoline) engine with a multipoint electronic injection system and integrated ignition control unit. It showcases critical engine systems such as the electro-injector, throttle body, control unit, and LAMBDA probe, sectioned for enhanced visibility. The model includes an overhead camshaft (OHC), toothed belt timing, and essential sensors like an air temperature sensor and throttle potentiometer, offering a comprehensive view of modern internal combustion engine technology.

Request a quote

Check our catalog and product data sheet

Download the Full AutoEDU Product Catalogue

Enter your details to receive the AutoEDU catalogue with automotive training systems, laboratory equipment, technical specifications, and solutions for universities, technical colleges, and training centers.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Download the Full Technical Data Sheet

Enter your details to receive the complete technical documentation for this AutoEDU training system, including product description, specifications, and key features for automotive training applications.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Features

Overhead camshaft (OHC) system with toothed belt timing for realistic training.
Cutaway electro-injector, throttle body, and control unit for detailed component analysis.
Integrated sensors, including air temperature sensor and throttle potentiometer, for modern diagnostics study.
Chromium-plated and galvanized components for extended durability.
Manually operated crank handle for practical demonstration of mechanical motion.

Value for Students

Provides detailed insight into the working principles of a multipoint injection engine, enabling the study of injection, ignition, and sensor integration.
Enhances understanding of fuel system operation through sectioned components, including the electro-injector, throttle body, and LAMBDA probe.
Offers hands-on learning with a manually operated crank handle, allowing students to observe real-time mechanical motion.
Supports the study of critical sensors, such as the air temperature sensor and throttle potentiometer, emphasizing their role in efficient engine control.
Demonstrates lubrication and cooling circuits, fostering a clear understanding of engine maintenance and operational efficiency.

Value for Instructors

Simplifies the teaching of modern engine components and systems with color-coded sections for clarity.
Provides a practical tool for explaining complex topics like injection timing, ignition processes, and emission control.
Enhances lesson engagement by offering hands-on interaction with real engine components.
Enables detailed observation of cross-sections, allowing instructors to highlight key mechanical and electronic systems.
Durable and portable design ensures ease of use in varied classroom settings.

Specifications

Dimensions: 500 x 450 x 800 mm (19.69 x 17.72 x 31.50 in)
Approx. weight: 21 kg (46.3 lbs)
Product number: AE47490M
