Steam Engine Model Cutaway AE39220M

Home

Cutaways

AutoEDU

Product number: AE39220M

ASE category: A1

Manually operated with rotating flywheel.
Horizontal single-cylinder steam engine structure.
Integrated piston valve with visible cutaway section.
Mechanical centrifugal governor included.

Request a quote

Check our catalog and product data sheet

Download Catalogue

Description

Educational steam engine model featuring a horizontal single-cylinder design with integrated piston valve and centrifugal governor mechanism. Built with visible internal components to demonstrate working principles. Operated manually through a flywheel, enabling real-time observation of motion transmission, valve control, and mechanical energy conversion.

Specifications

Product type: Steam engine educational model.
Cylinder type: Horizontal single-cylinder with piston valve.
Control: Manual flywheel rotation.
Governor: Centrifugal mechanical type.
Weight: 3 kg (6.6 lbs).
Dimensions: 360 × 220 × 340 mm (14.17 × 8.66 × 13.39 in).
Product number: AE39220M

Value for Students

Understand steam engine working principles: cylinder pressure, piston displacement, and rotary motion.
Observe piston valve timing and steam distribution cycle.
Study motion transfer from piston to crank via connecting rod.
Identify centrifugal governor operation and feedback control principles.
Learn mechanical linkage interaction: crankshaft, flywheel, and valve gear.
Practice mechanical analysis of single-acting steam engine systems.

Value for Instructors

Provides clear visual demonstration of piston valve and governor mechanism.
Manual operation ensures controlled teaching at any pace.
Enables mechanical system explanation without external power.
Suitable for classroom, laboratory, or mobile teaching setups.
Supports fundamental education in thermodynamics and mechanical motion.
Ideal for technical schools, vocational education, and introductory engineering courses.
