Line Strainer Valve Cutaway AE513138S

Home

Cutaway Models - Engines, Gearboxes & Drivetrain

AutoEDU

Product number: AE513138S

Real line strainer valve cross-section.
Visible mesh filter and fluid flow channels.
Durable housing with precise cutaway section.

Request a quote

Check our catalog and product data sheet

Download the Full AutoEDU Product Catalogue

Enter your details to receive the AutoEDU catalogue with automotive training systems, laboratory equipment, technical specifications, and solutions for universities, technical colleges, and training centers.

I agree to the processing of my personal data in accordance with the Privacy Policy.

Description

Educational tool showing a real cutaway of a line strainer valve. Mounted for demonstration and training. The trainer shows the internal filter structure and housing. It is designed for understanding basic fluid control systems in automatic transmission applications. This model is made using actual components and allows visual inspection of flow paths, filter mesh, and sealing zones.

Specifications

Product type: Cutaway line strainer valve trainer.
Material: OEM metal valve with internal mesh screen.
Weight: 1 kg (2.2 lbs).
Dimensions: 150 x 150 x 100 mm (5.91 x 5.91 x 3.94 in).
Product number: AE513138S
