Pressure Valve Reducer With Female Connection Cutaway AE513144S

Pressure Valve Reducer With Female Connection Cutaway AE513144S

AutoEDU

Product number: AE513144S

Industrial-type pressure reducer with cutaway design.
All key components clearly visible: spring, diaphragm, valve body, seat.
Female connection type for realistic application reference.

Request a quote

Check our catalog and product data sheet

Description

Cutaway model of a pressure valve reducer with a female threaded connection. Internal components are fully exposed to allow visual inspection and analysis of the pressure regulation system. The device illustrates how pressure is reduced and controlled in pneumatic or fluid systems. Constructed from industrial-grade parts, sectioned precisely for durability and repeatable classroom use.

Specifications

Type: Pressure valve reducer cutaway.
Connection: Female threaded.
Mounting: Fixed base or table-top.
Weight: 1 kg (2.2 lbs).
Dimensions: 100 x 100 x 50 mm (3.94 x 3.94 x 1.97 in).
Product description: AE513144S
