Toyota Prius III Petrol/Electric/LPG HYBRID ¾ Educational Trainer PMTPK05

• Based on the Toyota Prius III with a hybrid system and LPG supply system.
• Open sections of roof, fender, door trim, high voltage battery, LPG system for clear visibility and safe learning.
• Integrated LPG system with gas equipment and safety elements with visible pressure gauge, gas filling and supply lines, safety valve.
• Complete climate control system.
• ABS, stability control, and SRS airbag systems with exposed components for training.
• CAN Bus Network. Facilitates understanding of data communication within the vehicle.
• Safe access to high-voltage battery, fuses, inverter, vires with plexiglass covers for safe educational purposes.
• OBD 16-pin diagnostic connector for ECU identification, fault code management, and live data display.

• OEM hybrid system and LPG supply, learn body, chassis structures, passive and active safety systems.
• Provides easy, safe, and comfortable training that builds confidence, using OEM components to offer a realistic car repair experience.
• Learn the specifics of hybrid systems, including operation modes and diagnostic procedures in safe and comfortable environment.
• Study sectioned and opened car areas, providing clear view into structural and safety elements. Sections of the car roof, one side of the front fender, and interior door trim are open and removed to expose parts clearly, safely, and visibly. The high-voltage battery is open and covered with safety glass for secure access to all essential components.
• High voltage wires running from the battery to the engine compartment are visible through safety glass. Safe and convenient access for maintenance high voltage fuse that disconnects battery. The inverter, with the top cover removed for structural learning, is covered with safety glass.
• Perform various system measurements, monitor real parameters, and engage in diagnostic tasks using multiple tools like OBD diagnostic scan tool, oscilloscope, the gas analyzer, the exhaust extraction system or air conditioning service station and more.
• Engine is equipped with liquefied petroleum gas supply system (LPG) to understand the structure and operation of the system.  Gas filling valve wit adapter is installed at the petrol/gasoline filling point, gas cylinder is installed in the space wheel place. Pressure gauge, gas filling and supply lines, safety valve are visible.
• Understand the operation of ABS, stability control, and airbag systems with exposed and deactivated components for detailed study.
• Use OBD 16-pin diagnostic connectors for comprehensive fault code management and live data monitoring. Learn to read/erase fault codes, control or configure control unit, test actuator.

• Fully functional model to demonstrate the workings of hybrid car systems, LPG supply system, body, chassis structures, passive and active safety systems.
• Uses OEM automotive parts for an authentic and practical learning experience. Students gets real experience with all parts and functions exact as in real cars.
• Ensure student safety with disengaged drive-wheel drive and protective plexiglass covers on high-voltage components.
• The model’s robust construction and mobile chassis allow for easy classroom integration, mobility and longevity.
• Provide students with practical experience in diagnosing and troubleshooting using OBD diagnostic tool, oscilloscope, the gas analyzer, the exhaust extraction system or air conditioning service station and more.
• Training aid on castors version, which is mobile and space saving in the classroom, allows concurrent use by multiple students, promoting collaborative learning and practical training opportunities.
• The training stand is designed for simplicity, requiring only small adjustments to reset to default parameters, making it easy to prepare and start each lesson quickly and efficiently.

• Dimensions: 4460 x 1745 x 1510 mm (175.59 in x 68.70 in x 59.45 in)
• Weight: approx. 1805 kg
• Power supply: 12V battery, high-voltage battery pack (~200V), gasoline A91 or higher
• Safety equipment: protective tools set EHVS01 (optional)
• Product number: PMTPK05

• Built-in measuring box with open contacts and wiring diagram for engine control system
• Fault simulation for engine control system
• Built-in measuring box with open contacts and wiring diagram for climate control
• Fault simulation for climate control
• Built-in measuring box with open contacts and wiring diagram for SRS AIRBAG
• Fault simulation for SRS AIRBAG

Optional tools and equipment for measurement and services

• Oscilloscope
• OBD Diagnostic scan tool
• The gas analyzer
• The exhaust extraction system
• Air Conditioning service station

To ensure the highest safety standards, the Protective Tools Set EHVS01 must be included with all orders of our Electric Vehicle (EV) and Hybrid Trainers. This essential set is designed to provide comprehensive protection and support for users during training sessions. If the EHVS01 Protective Tools Set is not required, please contact our managers to adjust your quotation accordingly.
