Standard Bore Ball Valve Cutaway AE513130S

Standard Bore Ball Valve Cutaway AE513130S

AutoEDU

Product number: AE513130S

Clear cross-section for internal visibility.
Rotating ball with bore hole.
Full valve body with seals and seating areas.
Valve handle included for manual rotation demonstration.

Request a quote

Check our catalog and product data sheet

Description

Automotive training equipment built to demonstrate internal structure and operation of a standard bore ball valve. Made of metal components with clear internal cutaway. Designed for safe and simple demonstration of ball valve flow control principles in closed-loop systems.

Specifications

Type: Ball valve (standard bore).
Internal design: Cutaway with full port visibility.
Dimensions: 150 x 150 x 150 mm (5.91 x 5.91 x 5.91 in).
Weight: 1 kg (2.20 lbs).
Product number: AE513130S
